How To Setup Django Site In Linux Vps

by abhilash - March 15, 2021 coding

1) Buy a VPS Server

for setting up django web app in centos/Rhel vps system you have to buy vps server from vps provider it will give you server ip address and root password  also you will get  client web gui for management of server from that you get access to  reset server ,reinstall server or boot sever into safe mode and  from there you can even change the root password

2) ssh the server

now ssh the sever from any ssh client like putty ,cmd or mobxtrem,etc.

ssh root@192.168.47.101 ---> give root password of server

after that you will get the full access that server

3)Change the root password

once you login to ssh server you should change  your root password by passwd commnad

passwd root --> give new password two times

4) add a new user

add a new user so you dont needed to use root for all the times it will make your server more secure

useradd test

passwd test -->  give new password two times

now add that test user to wheel group so you can use sudo command by sudo command you can access all system  command by that new user

usermod -G wheel test

5) Configure ssh

configure ssh so  no one can login to the system via root  , edit  ssh configuration file and write PermitRootLogin to No



vim   /etc/ssh/sshd_config

       PermitRootLogin to No

now reboot the system and login via ssh  by ssh user@server



6)update the system

now update the system then reboot the system

e.g yum update && reboot

7)Install python3

after sucessfully update install python3

yum install python3

8)install and activate virtual enviroment

after installation of python3 we can use python pip package installer by using pip we can install and create virtual enviroment

by using virtual enviroment we can install python packages virtually that means they only available when we activate the virtual enviroment



pip3 install virtualenv

9)activate virtual enviroment

for activation of virtual enviroment  create new directory use source command to activate it

mkdir /djangoenv

virtualenv /djangoenv

source /django/bin/activate

10)install python packages

first create the requirement.txt ,in that file write list of names of python packages

now install it by

pip install -r requirements.txt



11) install sqlite3.8

for django to work in python3  in centos it need the sqlite version 3.8

wget https://kojipkgs.fedoraproject.org//packages/sqlite/3.8.11/1.fc21/x86_64/sqlite-3.8.11-1.fc21.x86_64.rpm

sudo yum install sqlite-3.8.11-1.fc21.x86_64.rpm



12)copy django application to server

copy django application to server by using scp or sftp

scp djangoapplication.zip user@server



13)test the django application

python3 manage.py runserver



14)install apache webserver

install apache webserver

yum install httpd*



15) configure apache server

go to /etc/httpd/conf.d

create web.conf file

type configuration

<virtual host *:80>

servername yoursitename

alias /static  /your static directory in django application

alias /media /your media directory in django application

<directory  /your static direcory >

require all granted

</directory>

<directory  /your media directory >

require all granted

</directory>

<directory /your main app directory where wsgi file located>

<files wsgi.py>

require all granted

</files>

</directory>

WSGIDaemonProcess name_of_your_project python-path = /directory of project

python-home = /directory of enviroment variables'

WSGIProcessGroup  name_of_project

WSGIScriptAlias / /your django app directory

</virtualhost>

save and exit

if there is numpy python package in your django app then it will gives time out so add following line to

/etc/httpd/conf/httpd.conf

WSGIApplicationGroup % {GLOBAL}

save and exit



16)Restart apache server

test apache config by

apachectl configtest

restart apache server

systemctl restart httpd



17)go to web browser check your site

Done.

Create Replication Mysql

by abhilash - Oct. 7, 2025 coding

mysqld --defaults-file=/etc/my.cnf --initialize --user=mysql

In 8.4 Community, the host cache is managed internally.
FLUSH HOST DEPRICATED --> SELECT * FROM performance_schema.host_cache;


CREATE USER 'repl'@'%' IDENTIFIED BY 'password';
GRANT REPLICATION SLAVE ON *.* TO 'repl'@'%';
FLUSH PRIVILEGES;

CHANGE REPLICATION SOURCE TO
  SOURCE_HOST='192.168.241.101',
  SOURCE_USER='repl',
  SOURCE_PASSWORD='password',
  SOURCE_PORT=3360,
  SOURCE_AUTO_POSITION=1,
  SOURCE_SSL=1,
  SOURCE_SSL_CA='/data/ca.pem';





slave my.cnf




[mysqld]
datadir=/data/mysql_server
socket=/var/lib/mysql/mysql.sock
log-error=/data/mysql_server/mysqld.log
pid-file=/var/run/mysqld/mysqld.pid

server-id=2
log_bin=mysql-bin
binlog_format=ROW
gtid_mode=ON
enforce_gtid_consistency=ON
get_source_public_key=1

port=3360
user=mysql
symbolic-links=0

# Connection limits (safe for low-memory VM)
max_connections=50
max_user_connections=50

# Packet and temporary table sizes
max_allowed_packet=16M
tmp_table_size=32M
max_heap_table_size=32M

# Sorting and read buffers (per connection, smaller for low RAM)
sort_buffer_size=2M
read_buffer_size=2M
read_rnd_buffer_size=4M
join_buffer_size=2M

# Storage engine
default-storage-engine=InnoDB
key_buffer_size=8M
bulk_insert_buffer_size=8M

# InnoDB settings for small memory
innodb_log_file_size=32M
innodb_print_all_deadlocks=1
innodb_buffer_pool_instances=1
innodb_buffer_pool_size=512M
innodb_read_io_threads=4
innodb_write_io_threads=4
innodb_thread_concurrency=0
innodb_io_capacity=100
innodb_log_buffer_size=8M
innodb_flush_log_at_trx_commit=2
innodb_lock_wait_timeout=50

# Transaction isolation
transaction-isolation=READ-COMMITTED

[root@node2 data]#


============================



master my.cnf




[mysqld]
datadir=/data/mysql_server
socket=/var/lib/mysql/mysql.sock
log-error=/data/mysql_server/mysqld.log
pid-file=/var/run/mysqld/mysqld.pid

server-id=1
log_bin=mysql-bin
binlog_format=ROW
gtid_mode=ON
enforce_gtid_consistency=ON

plugin-load-add=mysql_native_password.so

port=3360
user=mysql
symbolic-links=0

# Connection limits (safe for low-memory VM)
max_connections=50
max_user_connections=50

# Packet and temporary table sizes
max_allowed_packet=16M
tmp_table_size=32M
max_heap_table_size=32M

# Sorting and read buffers (per connection, smaller for low RAM)
sort_buffer_size=2M
read_buffer_size=2M
read_rnd_buffer_size=4M
join_buffer_size=2M

# Storage engine
default-storage-engine=InnoDB
key_buffer_size=8M
bulk_insert_buffer_size=8M

# InnoDB settings for small memory
innodb_log_file_size=32M
innodb_print_all_deadlocks=1
innodb_buffer_pool_instances=1
innodb_buffer_pool_size=512M
innodb_read_io_threads=4
innodb_write_io_threads=4
innodb_thread_concurrency=0
innodb_io_capacity=100
innodb_log_buffer_size=8M
innodb_flush_log_at_trx_commit=2
innodb_lock_wait_timeout=50

# Transaction isolation
transaction-isolation=READ-COMMITTED


Secure Grafana + Prometheus + Node Exporter Monitoring Setup With Https And Django Embed

by abhilash - Dec. 28, 2025 coding

Secure Monitoring Setup – Prometheus + Node Exporter + Grafana (HTTPS + TLS + Django Embed)

OS: Rocky Linux 8.10 / RHEL compatible
Container runtime: Podman
TLS: Let’s Encrypt or self-signed
Grafana HTTPS port: 42923

Goal:
– node exporter & prometheus not public
– only localhost access
– grafana SSL enabled on random port
– disable anonymous login
– embed inside Django site
– force login authentication

=======================================

Create directories

mkdir -p /opt/node
mkdir -p /opt/prometheus
mkdir -p /opt/grafana/certs

=======================================
2) Copy SSL certificates for Grafana

Use Let’s Encrypt certs (recommended)

cp -L /etc/letsencrypt/live/www.yourdomain.com/fullchain.pem /opt/grafana/certs/fullchain.pem
cp -L /etc/letsencrypt/live/www.yourdomain.com/privkey.pem /opt/grafana/certs/privkey.pem

Fix permissions

chmod 640 /opt/grafana/certs/privkey.pem
chmod 644 /opt/grafana/certs/fullchain.pem

SELinux label

chcon -Rt container_file_t /opt/grafana/certs

=======================================
3) Create Node Exporter HTTPS config file

cat > /opt/node/web.yml <<EOF
tls_server_config:
cert_file: /certs/server.crt
key_file: /certs/server.key
EOF

If using self-signed:

copy cert files

cp /opt/ssl/selfsigned/server.crt /opt/node/
cp /opt/ssl/selfsigned/server.key /opt/node/

=======================================
4) Run Node Exporter (localhost only + HTTPS)

podman run -d
--name node_exporter
-p 127.0.0.1:9100:9100
-v /opt/node/web.yml:/etc/node/web.yml:Z
-v /opt/ssl/selfsigned/server.crt:/certs/server.crt:ro,Z
-v /opt/ssl/selfsigned/server.key:/certs/server.key:ro,Z
quay.io/prometheus/node-exporter
--web.config.file=/etc/node/web.yml
--web.listen-address=127.0.0.1:9100

Test

curl -k https://127.0.0.1:9100/metrics

=======================================
5) Create Prometheus config

cat > /opt/prometheus/prometheus.yml <<EOF
global:
scrape_interval: 5s

scrape_configs:

job_name: 'node'
scheme: https
tls_config:
insecure_skip_verify: true
static_configs:

targets: ['127.0.0.1:9100']
EOF

=======================================
6) Run Prometheus container

podman run -d
--name prometheus
-p 127.0.0.1:9090:9090
-v /opt/prometheus/prometheus.yml:/etc/prometheus/prometheus.yml:Z
prom/prometheus

Test local access

curl -k https://127.0.0.1:9090/api/v1/targets

You should see "health: up"

=======================================
7) Run Grafana HTTPS on port 42923

Remove any old container first

podman stop grafana || true
podman rm grafana || true

Run new

podman run -d
--name=grafana
--net=host
-v grafana:/var/lib/grafana
-v /opt/grafana/certs/fullchain.pem:/certs/fullchain.pem:ro,Z
-v /opt/grafana/certs/privkey.pem:/certs/privkey.pem:ro,Z
-e GF_SERVER_PROTOCOL=https
-e GF_SERVER_HTTP_PORT=42923
-e GF_SERVER_CERT_FILE=/certs/fullchain.pem
-e GF_SERVER_CERT_KEY=/certs/privkey.pem
-e GF_AUTH_ANONYMOUS_ENABLED=false
-e GF_USERS_ALLOW_SIGN_UP=false
-e GF_SECURITY_ALLOW_EMBEDDING=true
grafana/grafana:latest

Test

curl -k https://127.0.0.1:42923

Expected:

<a href="/login">Found</a>

Browser URL

https://www.yourdomain.com:42923

=======================================
8) First Grafana login

Default user:

admin / admin

Grafana will force you to CHANGE PASSWORD

Create user “xxxx” later in settings.

=======================================
9) Import dashboard ID 1860

In Grafana:
Dashboards → Import
Dashboard ID: 1860
Select Prometheus datasource

=======================================
10) Django embed setup

Create app: serverstats

views.py

from django.contrib.auth.decorators import login_required
from django.shortcuts import render

@login_required
def serverstats_home(request):
return render(request, "serverstats/home.html")

Template home.html

<h2>Server Monitoring Dashboard</h2> <iframe src="https://www.yourdomain.com:42923/d/xxxx?orgId=1&refresh=30s" width="100%" height="900" frameborder="0"> </iframe>

urls.py entry

path("serverstats/", serverstats_home, name="serverstats")

=======================================
11) Security notes

Node exporter is local only ✔
Prometheus is local only ✔
Grafana HTTPS enforced ✔
Random port 42923 ✔
Anonymous Grafana disabled ✔
Django auth required ✔
TLS everywhere ✔
